RAEGuard LEL

RAE Systems- RAEGuard LEL
Fixed Gas Monitor for Combustible Gases.

The RAEGuard LEL is a permanently mounted (fixed) catalytic bead combustible gas detector/transmitter that operates from a 9 to 36 VDC power source and provides an analog (4 to 20mA) and digital (RS-485) signal output in the range of 0 to 100%LEL combustible gas. Housed in an explosion-proof enclosure, the RAEGuard LEL is equipped with a local digital display of the gas concentration and function keys for performing calibration. The RAEGuard LEL can be operated with a standard 4 to 20mA/RS-485 controller or as a stand-alone sensor module.

Fixed Combustible Gas Monitor, 4 to 20mA/RS-485 Transmitter.

Key Features:

• Highly poison-resistant catalytic bead combustible gas LEL sensor
• 4 to 20mA analog and RS-485 digital output of 0 to 100%LEL combustible gas including methane, hydrogen or other combustible gases
• Explosion-proof enclosure for hazardous environment applications
• Local displays with adjustment keys
• Non-intrusive calibration
• Magnetic key interface eliminates need to open explosion-proof housing when making calibrations or other minor adjustments
• Operation at 9 to 36 VDC
• Dry-contact output (<30V, 2A)

  Hazardous Location Classification:

• UL: Class I, Division 1, Groups B, C, D
• Temperature Code T6
• Chinese Certificate: Ex d IICT6



  Applications:

  • Refineries
  • Oil production
  • Chemical plants
  • Industrial safety
  • Shipyards and maritime
  • Power plants
  • Steel mills
